Name: Curb Paint

Display Field: CW_ASSETID

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This dataset contains key attribute fields describing each curb paint asset. Note that values may be missing as this is an ongoing effort to reconcile and input our asset data. Notable/unique fields for Curb Paint include:CW_ASSETID – Active unique identifier associated with each asset in Trimble Unity Maintain / Cityworks. STATUS– Indicates the operational status of the curb paint asset, such as Active, Inactive, Proposed, or other approved status values. CURBCODE– Short curb paint code made up of “C” for curb and the curb color abbreviation. For example, CR represents Curb Red. CURB_COLOR – Identifies the color of the painted curb segment, such as red, blue, green, yellow, or white, depending on the approved domain values. HANDICAP– Indicates whether the curb paint asset is associated with a handicapped / accessible curb designation. This is generally expected to apply to blue curb assets. CURB_Height – Height of the curb, stored as a numeric value. CURB BEGIN FT – Beginning measurement of the curb paint segment in feet, based on its measured distance from the referenced street or location point. CURB END FT – Ending measurement of the curb paint segment in feet, based on its measured distance from the referenced street or location point. CURB LIN FT – Linear curb paint length in feet. This may be calculated from the difference between the curb ending and beginning measurements. ORIG_INST_DATE – Original installation date of the curb paint asset, when available. LAST_MAINT_DATE – Date the curb paint asset was last maintained, when available.Last updated or update frequency: 2026Loaded May 2026 per Ticket #258530Added STREET_SMART_ID, RECORDED_AT, and STREET_SMART_URL fields June 2026 per Ticket #260824

Copyright Text: Name: Haig Minasian Organization: Los Angeles County Public Works, Operational Services Division Position: Senior GIS Analyst Role: Point of Contact Email: hminasian@dpw.lacounty.gov Address: 900 s Fremont Ave City: Alhambra State: CA Postal Code: 91803 Phone: (626) 458-7104

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: NaN
YMin: NaN
XMax: NaN
YMax: NaN
Spatial Reference: 102645  (2229)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [255, 0, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• CW_ASSETID ( type: esriFieldTypeString, alias: TUMS Asset ID , length: 50 )
• ASSETNUM ( type: esriFieldTypeString, alias: MMS Asset ID MMS Asset ID , length: 50 )
• STATUS ( type: esriFieldTypeString, alias: Status, length: 25 , Coded Values: [UNKNOWN: UNKNOWN] , [ACTIVE: ACTIVE] , [ABANDONED: ABANDONED] , ...3 more... )
• CURBCODE ( type: esriFieldTypeString, alias: Curb Code, length: 2 , Coded Values: [CR: CR] , [CW: CW] , [CY: CY] , ...3 more... )
• HANDICAP ( type: esriFieldTypeString, alias: Handicapped, length: 3 , Coded Values: [Yes: Yes] , [No: No] )
• DESCRIPTION ( type: esriFieldTypeString, alias: Description, length: 500 )
• LR1 ( type: esriFieldTypeString, alias: LocRef1, length: 2 , Coded Values: [EA: EA] , [EB: EB] , [EM: EM] , ...13 more... )
• STREET ( type: esriFieldTypeString, alias: Street, length: 250 )
• LR2 ( type: esriFieldTypeString, alias: LocRef2, length: 2 , Coded Values: [EO: EO] , [EM: EM] , [EA: EA] , ...21 more... )
• CROSSING ( type: esriFieldTypeString, alias: Crossing, length: 250 )
• CURBBEGINFT ( type: esriFieldTypeInteger, alias: Curb Begin Ft )
• CURBENDFT ( type: esriFieldTypeInteger, alias: Curb End Ft )
• CURBLNFT ( type: esriFieldTypeInteger, alias: Curb Length Ft )
• CURBHEIGHTFT ( type: esriFieldTypeDouble, alias: Curb Height Ft )
• ROUTE ( type: esriFieldTypeString, alias: Route, length: 25 )
• CITY ( type: esriFieldTypeString, alias: City, length: 200 )
• JURISCODE ( type: esriFieldTypeString, alias: Jurisdiction, length: 25 , Coded Values: [116: 116] , [117: 117] , [118: 118] , ...27 more... )
• CURB_COLOR ( type: esriFieldTypeString, alias: Curb Color, length: 10 , Coded Values: [Red: Red] , [White: White] , [Yellow: Yellow] , ...3 more... )
• CURB_TYPE ( type: esriFieldTypeString, alias: Curb Type, length: 25 , Coded Values: [A2-6: A2-6] , [A2-8: A2-8] , [A1-6: A1-6] , ...3 more... )
• ORIG_INST_DATE ( type: esriFieldTypeDate, alias: Original Install Date, length: 8 )
• LAST_MAINT_DATE ( type: esriFieldTypeDate, alias: Last Maintained Date, length: 8 )
• CREATED_USER ( type: esriFieldTypeString, alias: Created User, length: 255 )
• CREATED_DATE ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• LAST_EDITED_USER ( type: esriFieldTypeString, alias: Last Edited User, length: 255 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: Last Edited Date, length: 8 )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GLOBALID, length: 38 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.LEN ( type: esriFieldTypeDouble, alias: SHAPE.LEN )
• STREET_SMART_ID ( type: esriFieldTypeString, alias: Street Smart ID, length: 255 )
• RECORDED_AT ( type: esriFieldTypeDate, alias: Recorded At, length: 8 )
• STREET_SMART_URL ( type: esriFieldTypeString, alias: Street Smart URL, length: 255 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
