Name: Pavement Marking

Display Field: CW_ASSETID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This dataset represents the locations and attributes of pavement marking assets maintained by the Los Angeles County Department of Public Works (DPW), Operational Services Division (OSD). Pavement markings include surface-applied roadway features such as symbols, legends, stop bars, crosswalks, text markings, and other traffic control devices that convey regulatory, warning, or guidance information to roadway users.Each asset record represents a single marking type, defined by a standardized marking code (MARKCODE), and may include a quantity of that marking within the defined asset extent. For example, an asset may represent multiple instances of the same marking type (e.g., multiple stop bars or symbols) grouped within a single record.Marking locations are defined using linear referencing along roadway segments, incorporating street names, cross streets, and directional distance measurements to establish the spatial extent of each asset.Attributes are structured to align with DPW asset management standards and include references to Caltrans Standard Plans, MUTCD classifications, and material and reflectivity properties. The dataset supports asset inventory tracking, maintenance planning, and integration with the County’s Asset Management System (Trimble Unity Maintain / Cityworks).Field Definitions / Attribute Overview:This dataset contains key attribute fields describing each pavement marking asset. Note that values may be missing as this is an ongoing effort to reconcile and input our asset data. Notable/unique fields for Markings include:CW_ASSETID – Unique asset identifier assigned within the Cityworks / Trimble Unity Maintain system.STATUS – Operational status of the pavement marking asset (e.g., Active, Inactive, Proposed).MARKCODE – Standardized DPW marking code identifying the specific type of pavement marking.DESCRIPTION – General description of the marking asset.STREET – Name of the roadway where the marking is located.LR1 / LR2 – Linear referencing identifiers describing the relative placement of the marking along the roadway.CROSSING – Indicates whether the marking is associated with a crossing feature (e.g., crosswalk).DIST_FT – Distance measurement (in feet) used to define the location or extent of the marking.MARK_QTY – Number of individual markings of the same type within the asset.MKG_SQ_FT – Total area of the marking(s) in square feet.MARK_CATEGORY – High-level classification of the marking (e.g., regulatory, warning, guidance).MARK_TYPE – Specific type grouping of the marking.MARK_LABEL – Text label associated with the marking (if applicable).MARK_SYMBOL – Symbol designation for the marking (if applicable).CT_PLAN – Reference to the applicable Caltrans Standard Plan.CT_DETAIL – Specific Caltrans detail associated with the marking.MUTCD_REF – Reference to the applicable MUTCD standard or code.MARK_COLOR – Color of the pavement marking (e.g., white, yellow).MARK_MATERIAL – Material used for the marking (e.g., paint, thermoplastic).RRFLTY – Numeric retroreflectivity score representing the amount of light reflected from the marking or striping, used to assess its nighttime visibility and overall condition.MLOC_TYPE – Type of location where the marking is applied (e.g., roadway, intersection).MLANE_USE – Lane use designation associated with the marking (e.g., turn lane, bike lane).ORIG_INST_DATE – Original installation date of the marking. LAST_MAINT_DATE – Most recent maintenance or reapplication date.Last updated or update frequency: 2026Loaded May 2026 per Ticket #259688

Copyright Text: Name: Haig Minasian Organization: Los Angeles County Public Works, Operational Services Division Position: Senior GIS Analyst Role: Point of Contact Email: hminasian@dpw.lacounty.gov Address: 900 s Fremont Ave City: Alhambra State: CA Postal Code: 91803 Phone: (626) 458-7104

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: NaN
YMin: NaN
XMax: NaN
YMax: NaN
Spatial Reference: 102645  (2229)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [82, 42, 163, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• CW_ASSETID ( type: esriFieldTypeString, alias: TUMS Asset ID, length: 50 )
• ASSETNUM ( type: esriFieldTypeString, alias: MMS Asset ID, length: 50 )
• STATUS ( type: esriFieldTypeString, alias: Status, length: 25 , Coded Values: [UNKNOWN: UNKNOWN] , [ACTIVE: ACTIVE] , [ABANDONED: ABANDONED] , ...3 more... )
• MARKCODE ( type: esriFieldTypeString, alias: Marking Code, length: 10 )
• DESCRIPTION ( type: esriFieldTypeString, alias: Description, length: 500 )
• LR1 ( type: esriFieldTypeString, alias: LocRef1, length: 2 , Coded Values: [EA: EA] , [EB: EB] , [EM: EM] , ...13 more... )
• STREET ( type: esriFieldTypeString, alias: Street Name, length: 250 )
• LR2 ( type: esriFieldTypeString, alias: LocRef2, length: 2 , Coded Values: [EO: EO] , [EM: EM] , [EA: EA] , ...21 more... )
• CROSSING ( type: esriFieldTypeString, alias: Crossing, length: 250 )
• DIST_FT ( type: esriFieldTypeDouble, alias: Distance from Intersection (Ft) )
• MKG_SQ_FT ( type: esriFieldTypeDouble, alias: Marking Area in Sq. Ft. )
• MARK_QTY ( type: esriFieldTypeSmallInteger, alias: Number of Markings )
• JURISCODE ( type: esriFieldTypeString, alias: Jurisdiction, length: 25 , Coded Values: [116: 116] , [117: 117] , [118: 118] , ...27 more... )
• MARK_CATEGORY ( type: esriFieldTypeString, alias: Marking Category, length: 30 , Coded Values: [Arrow: Arrow] , [Word: Word] , [Symbol: Symbol] , ...8 more... )
• MARK_TYPE ( type: esriFieldTypeString, alias: Marking Type, length: 50 , Coded Values: [Left Arrow: Left Arrow] , [Right Arrow: Right Arrow] , [Through Arrow: Through Arrow] , ...22 more... )
• MARK_LABEL ( type: esriFieldTypeString, alias: Pavement Label Text, length: 50 )
• MARK_SYMBOL ( type: esriFieldTypeString, alias: Marking Symbol Type, length: 50 , Coded Values: [Arrow: Arrow] , [Diamond: Diamond] , [Bicycle: Bicycle] , ...4 more... )
• CT_PLAN ( type: esriFieldTypeString, alias: CalTrans Standard Plan, length: 10 , Coded Values: [A24A: A24A] , [A24B: A24B] , [A24C: A24C] , ...5 more... )
• CT_DETAIL ( type: esriFieldTypeString, alias: CalTrans Standard Detail Code, length: 10 )
• MUTCD_REF ( type: esriFieldTypeString, alias: CA MUTCD Reference, length: 15 )
• MARK_COLOR ( type: esriFieldTypeString, alias: Marking Color, length: 15 , Coded Values: [White: White] , [Yellow: Yellow] , [Red: Red] , ...3 more... )
• MARK_MATERIAL ( type: esriFieldTypeString, alias: Marking Material, length: 25 , Coded Values: [Thermoplastic: Thermoplastic] , [Paint: Paint] , [Epoxy: Epoxy] , ...3 more... )
• RRFLTY ( type: esriFieldTypeDouble, alias: Marking Retroreflectivity )
• MLOC_TYPE ( type: esriFieldTypeString, alias: Marking Location Type, length: 30 , Coded Values: [Intersection: Intersection] , [Midblock: Midblock] , [Ramp: Ramp] , ...4 more... )
• MLANE_USE ( type: esriFieldTypeString, alias: Marking Lane Use Type, length: 30 , Coded Values: [General Purpose: General Purpose] , [Left Turn: Left Turn] , [Right Turn: Right Turn] , ...4 more... )
• ORIG_INST_DATE ( type: esriFieldTypeDate, alias: Original Install Date, length: 8 )
• LAST_MAINT_DATE ( type: esriFieldTypeDate, alias: Last Maintained Date, length: 8 )
• CREATED_USER ( type: esriFieldTypeString, alias: Created User, length: 255 )
• CREATED_DATE ( type: esriFieldTypeDate, alias: Created Date, length: 8 )
• LAST_EDITED_USER ( type: esriFieldTypeString, alias: Last Edited User, length: 255 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: Last Edited Date, length: 8 )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GLOBALID, length: 38 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
